Beacon light
It is a type of traffic light installed on certain offshore structures to ensure the safe navigation of ships at night. It emits a specified light color and flash frequency at night, reaching a specified illumination angle and visibility distance.
Key:
Category:
Foghorn obstacle light navigation aid system
产品附件：
Hotline:
Beacon light
图文详情
APPLICATION SCOPE
It is a type of traffic light installed on certain offshore structures to ensure the safe navigation of ships at night. It emits a specified light color and flash frequency at night, reaching a specified illumination angle and visibility distance.
MAIN FEATURES
1. The shell is made of 316L stainless steel, and the lampshade is anti-ultraviolet PC;
2. Using high luminous efficiency, long life, green environmental protection SMD LED light source, the average life of the light source is more than 50,000 hours
Flicker frequency
1.The source of the beacon light is LED, the color rendering is white, and the number is not more than 6;
2.The minimum visual intensity of the beacon lamp is 1400cd, and the range can reach 10 nautical miles:
3.The vertical distribution of the outgoing beam should ensure that the maximum range can be seen
4.GPS wireless synchronization.
STANDARDS AND CERTIFICATES
IEC 60598 IEC 60092 IEC 62722 GD03-2008 GB7000 GB3836
GB4696 "China Sea Area Water Navigation Aid Mark"
Safety Rules for Fixed Offshore Platforms
Maritime Safety Authority's Statutory Inspection Rules for Ships and Offshore Facilities
CCS Code for Classification and Construction of Offshore Single Point Moorings
CCS Classification Specification for Offshore Mobile Platforms
CCS Code for Classification and Construction of Offshore Fixed Platforms
Recommendations of the International Navigation Association on Marking on Offshore Structures
